Achromatic F-Theta Scan Lens-355nm
Achromatic F-Theta Scan Lens-355nm
| wave | EFL | Scan | Input | Scan | Center-Edge | WD | Outer | Screw | |
| Product ID | length | Field | Beam | Angle | Spot Size | DiaXL | Thread | ||
| （nm） | （mm） | (mm) | (mm) | θ(°) | Φ(µm) | (mm) | (mm) | (mm) | |
| SLA-355-633-170-90-D10 | 355/633 | 170 | 90X90 | 10 | ±22º | 15-15.5 | 106.7 | Φ101X126 | M85X1 |
| SLA-355-633-220-110-D10 | 355/633 | 220 | 110X110 | 10 | ±20º | 11-12 | 165.4 | Φ100X118 | M85X1 |
| SLA-355-633-330-210-D6 | 355/633 | 330 | 210X210 | 6 | ±25º | 44-46 | 265 | Φ117X109 | M85X1 |
| SLA-355-532-170-100-D10 | 355/532 | 170 | 90X90 | 10 | ±22º | 13.2-13 | 125.6 | Φ106X124 | M85X1 |
